CR1
ultra-compact screen system- RBN401 pro-ribbon HF driver, 6.5” midrange and 12” woofer
- Adjustable HF driver for precise projection
- Industries most-shallow enclosure (18cm/7-in.)
- Signal Integrity Sensing™ pre-wired cable compensation
- ‘Real-90’ dispersion, H 90° x V 40° (nom.)
- Flown, stacked, wall-mount positioning
- Also available in “Front-Vent” version for baffle-wall mounting

CR2
compact screen system- RBN601 pro-ribbon HF driver, double 8” midrange and 15” woofer
- Adjustable HF driver for precise projection
- Ultra-shallow enclosure (25cm/10”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Dispersion H 90° x V 40° (line-source)
- Bi-amp or single-amp operation for economical powering
- Flown, stacked, wall-mount positioning
- Also available in “Front-Vent” version for baffle-wall mounting

CR3
medium-format screen system- Double RBN401 pro-ribbon HF driver, double 6.5” midrange and double 15” woofer
- Adjustable MHF waveguide with 10-degree pre-tilt for easy projection
- Shallow system design (35cm/13.7”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Bi-amp filtering for economical powering or tri-amp filtering for maximum output

CR4
large-format screen system- Triple RBN401 pro-ribbon HF driver, quad 6.5” midrange and double 15” woofer
- Unique HF array for extended throw / coverage compensation
- Adjustable MHF waveguide with 10-degree pre-tilt for easy projection
- Shallow system design (35cm/13.7”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Bi-amp filtering for economical powering or tri-amp filtering for maximum output

CRA24N Cinemarray™
scalable medium-format line-source screen system- Double RBN401 pro-ribbon HF driver, double 6.5” midrange and double 12” woofer
- Designed for short to medium-throw applications
- Flat front-to-rear SPL and projection control
- Shallow system design (32,4 cm/12.8”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Bi-amp filtering for economical powering
- Available in CRA24N (“narrow”), CRA24W (“wide”) and CRA24WX ("extended wide")

CRA24W Cinemarray™
scalable medium-format line-source screen system- Double RBN401 pro-ribbon HF driver, double 6.5” midrange and double 12” woofer
- Designed for short to medium-throw applications
- Flat front-to-rear SPL and projection control
- Shallow system design (31,7 cm/12.5”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Bi-amp filtering for economical powering
- Available in CRA24N (“narrow”), CRA24W (“wide”) and CRA24WX ("extended wide")

CRA24WX Cinemarray™
scalable medium-format line-source screen system- Double RBN401 pro-ribbon HF driver, double 6.5” midrange and double 12” woofer
- Designed for short to medium-throw applications
- Flat front-to-rear SPL and projection control
- Shallow system design (41,5 cm/16.3”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Bi-amp filtering for economical powering
- Available in CRA24N (“narrow”), CRA24W (“wide”) and CRA24WX ("extended wide")

CRA30N Cinemarray™
scalable large-format line-source screen system- Triple RBN401 pro-ribbon HF driver, triple 6.5” midrange and double 15” woofer
- Designed for short to long-throw applications
- Flat front-to-rear SPL and projection control
- Shallow system design (36,8cm/14,5”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Bi-amp filtering for economical powering or tri-amp filtering for maximum output
- Available in CRA30N (“narrow”) and CRA30W (“wide”)

CRA30W Cinemarray™
scalable large-format line-source screen system- Triple RBN401 pro-ribbon HF driver, triple 6.5” midrange and double 15” woofer
- Designed for short to long-throw applications
- Flat front-to-rear SPL and projection control
- Shallow system design (36,8cm/14,5”) for space economic mounting
- Signal Integrity Sensing™ pre-wired cable compensation
- Bi-amp filtering for economical powering or tri-amp filtering for maximum output
- Available in CRA30N (“narrow”) and CRA30W (“wide”)

CCS6
small-format surround- 1” exit compression driver with 6.5” woofer in coaxial configuration
- High power handling; 165W. continuous (AES)
- 90° conical dispersion
- Available in 2 different cabinet designs (wall / ceiling mount)
- Ideal for immersive surround or acoustical enhancement systems

CCS8
medium-format surround- 8” woofer with 1” compression driver in co-axial configuration
- High power handling: 305W continuous (AES)
- 80° conical dispersion
- Available in 2 different versions CCS8, CCS8S
- 10° slanted baffle for optimised projection
- Ideal for immersive ceiling surround or acoustical enhancement systems

CRS8/9040
medium-format reference surround- RBN401 pro-ribbon HF driver with 8” vented woofer
- Signal Integrity Sensing™ pre-wired cable compensation
- ‘Real-90’ dispersion, H 90° x V 40° (nom.)
- 10° slanted baffle for optimised projection
- Choice of 2 impedance versions: 4 ohms (immersive) or 8 ohms (5.1/7.1)
- Available in any color through the ACO™ RAL color option scheme

CRS8/9090
medium-format wide-angle reference surround- RBN401 pro-ribbon HF driver with 8” vented woofer
- Signal Integrity Sensing™ pre-wired cable compensation
- "Non-compression" waveguide with H 90° x V 90° dispersion
- 10° slanted baffle for optimised projection
- Choice of 2 impedance versions: 4 ohms (immersive) or 8 ohms (5.1/7.1)
- Available in any color through the ACO™ RAL color option scheme

CCS12
large-format surround- 12” woofer with 2” compression driver in co-axial configuration
- High power handling; 430W continuous (AES)
- 80° conical dispersion
- Low impedance for efficient amplifier loading
- Available in 2 different versions CCS12, CCS12S
- Ideal for immersive ceiling surround or acoustical enhancement systems

CRS12/9040
large-format reference surround- RBN401 pro-ribbon HF driver, 12” Neodymium woofer
- Signal Integrity Sensing™ pre-wired cable compensation
- ‘Real-90’ dispersion, H 90° x V 40° (nom.)
- 10° slanted baffle for optimised projection
- Choice of 2 impedance versions: 4 ohms (immersive) or 8 ohms (5.1/7.1)
- Available in any color through the ACO™ RAL color option scheme

CRS12/9090
large-format reference surround- Reference-quality wide dispersion immersive surround sound system
- Unique voicing match with Alcons pro-ribbon loaded screen systems
- 1:1 non-compressed sound reproduction, with up to 90% less distortion
- RBN401 pro-ribbon HF driver with exceptional intelligibility and dynamic output
- SIS™ pre-wired for very high damping and further reduced distortion (with ALC)
- Patented “Real-90” horizontal and patent-pending vertical dispersion

CRS12GT/60
large-format high-output reference surround- RBN601 pro-ribbon HF driver, 12” Neodymium woofer
- Signal Integrity Sensing™ pre-wired cable compensation
- ‘Real-90’ dispersion, H 60° x V 30° (nom.)
- 10° slanted baffle + trapezoidal cabinet for optimised projection
- Choice of 2 impedance versions: 4 ohms (immersive) or 8 ohms (5.1/7.1)
- Available in any color through the ACO™ RAL color option scheme

CRS12GT/90
large-format high-output reference surround- RBN601 pro-ribbon HF driver, 12” Neodymium woofer
- Signal Integrity Sensing™ pre-wired cable compensation
- ‘Real-90’ dispersion, H 90° x V 40° (nom.)
- 10° slanted baffle + trapezoidal cabinet for optimised projection
- Choice of 2 impedance versions: 4 ohms (immersive) or 8 ohms (5.1/7.1)
- Available in any color through the ACO™ RAL color option scheme

CB151sl
compact shallow subwoofer system- Single 15” long-excursion woofer with 4 ohms impedance
- Lowest usable frequency 19Hz.
- Signal Integrity Sensing™ pre-wired cable compensation
- Space-economic design, only 10.8”/27.5cm deep
- Large, side-placed vents for improved flow capacity without moving the screen
- Also available in “Front-Vent” version for baffle-wall mounting

CB181sl
shallow subwoofer system- Single 18” long-excursion woofer with vented-spider
- Space-economic design: cabinet depth only 11”/27.5cm
- Lowest usable frequency 20 Hz
- SIS pre-wired for very high damping and speaker cable compensation (with ALC)
- Large, side-placed vents for improved flow capacity without moving the screen
- Also available in “Front-Vent” version for baffle-wall mounting

CB211sl
larger-format shallow subwoofer system- Single 21” extended-excursion woofer with 4 ohms impedance
- Lowest usable frequency 19 Hz
- Signal Integrity Sensing™ pre-wired cable compensation
- Space-economic design for easy wall / behind-screen positioning
- Large, side-placed vents for improved flow capacity without moving the screen
- Also available in “Front-Vent” version for baffle-wall mounting

CB362
high-output full-size subwoofer system- Double 18” long-excursion woofers with vented-spider and 4" voice-coil
- Lowest usable frequency 20 Hz
- High output, sustained fundamental sub response
- SIS pre-wired for very high damping and further reduced distortion (with ALC)
- Large, centrally placed vent for improved air velocity and flow capacity
- Clever bracing for rigid cabinet construction
