RR12

RR12 - point-source array module

  • Unique seamless arrayability up to/beyond 20kHz
  • A-symmetric patented 60° dispersion in the non-coupling plane
  • 1:1 non-compressed sound reproduction, with up to 90% less distortion
  • Pro-ribbon HF driver with exceptional intelligibility and 1:16 dynamic output
  • Very high acoustical power output with wide frequency response
  • SIS pre-wired for very high damping and further reduced distortion
  • All Neodymium drivers for excellent performance-to-weight ratio

Product description

The RR12 is a point-source array element, developed as “building block” to create tight packed arrays for controlled sound coverage in the widest variety of audience areas.

The system features the Alcons-proprietary RBN602rs 6” pro-ribbon driver and a custom-designed 12” woofer with 4” voice coil, dual-spider suspension with forced-venting; while both transducers have Neodymium motor structures, the RR12 has a very high performance-to-weight ratio.

The purpose-designed 6” pro-ribbon driver is based on Alcons’ all-new “RBN02” pro-ribbon platform; This platform dramatically raises the bar in power handling and efficiency of pro-ribbon transducer technology.

The RBN602rs is coupled to an asymmetric “Morph-Max™” wave-guide, designed using the latest, state-of-the-art development tools: Proprietary-programmed analysis/simulation software in combination with 3D-prototyping and special manufacturing techniques, resulted in this non-compressing, resonance-free multi-cell guide with wide-band razor-sharp directivity control up to beyond 20kHz..

The trapezoidal cabinet is fitted with integrated mounting hardware, enabling array assembly with just a single operation from the rear of the cabinet.

Tight-packing the RR12 in horizontal or vertical arrays for stacked or flown applications, dispersion patterns are formable in increments of 30°; 30°, 60°, 90°, 120° in the coupling plane, by asymmetric 60° (+20°/-40°) in the non-coupling plane.

The RR12 is driven by the Sentinel amplified loudspeaker controller; The system’s response is optimised by factory presets for each array configuration, including presets for phase-matched low-frequency extensions.

The Signal Integrity Sensing™ pre-wiring ensures complete cable/connector compensation between the RR12 and Sentinel, resulting in a fast and tight mid and bass response, while reducing distortion even further.

Utmost reliability is one of the main essentials for Alcons systems: Each transducer/processing design has to pass a rigorous 1000 hour test at maximum (clip) levels. This is a key element in Alcons’ system development.

Each array configuration can be simulated in the Alcons Ribbon Calculator (ARC), Alcons’ high-resolution 3D simulation program.

Dimensional drawing

Technical specifications

Frequency Response

69 Hz - 20.000 Hz    (+/- 3dB)
51 Hz -(+/-10dB)

Sensitivity nominal   105 dB (200 Hz - 10 kHz)
Nominal Impedance   8 ohms
Recommended Drive   Sentinel10, max. 3 pcs. per channel (2.7 ohms)
Nominal SPL peak

135 dB (Sentinel10 200 Hz - 10 kHz)

Dispersion

H 30° x V +20°/-40° (@ 20 kHz)

Physical specifications

System   2-way, full range
Filtering   passive
Driver LF   1x AW12.4ND-8 12”, vented
Driver HF   1x RBN602rs 6” pro-ribbon driver
Connectors   2x Speakon NL4 input/link
Physical dimensions   mm        inches
Height   770        30.3
Width   347        13.7
Depth   462        18.2
Netto Weight (approx.)   29,5 kg    65.0 lb
Warranty   6 years limited
